Main Board

Main Board Name	X7CE
CPU	Intel® Bay Trail Mobile Desktop SoC Processor: Celeron® J1900 (4 cores, up to 2.42 GHz, max. TDP 10 Watts)
System Memory	SO-DIMM DDR3L x 1067/1333MHz, Max. 8GB.
Graphic	Intel® HD Graphics
BIOS	Phoenix uEFI BIOS
O.S. Support	Windows 7, WES 7, POSReady 7 Windows 8, Windows Embedded 8 Standard/Industry Retail Windows 10
EC	EBN-specified embedded controller
Cooling Solution	Fanless conductive thermal module

Display

Size	15.6" TFT LCD Panel
Panel backlight type	LED Backlight
Brightness	220 nits
Resolution	1366 x768
Touch Screen	P-cap

Storage Device

Interface	SATA x 2 (3.0Gb/S)
HDD or SSD	2.5" SATA HDD / SDD x 1 M.2 2242 SSD Slot x 1

Wireless Connectivities

Wi-Fi: Single Band

Wireless LAN module, M.2 2230 E-key (optional)

I/O Ports

COM Port	COM 1: DB9 RS232 x 1 (R1 / 5V / 12v by BIOS selection) COM 2: DB9 RS232 x 1 (R1 / 5V / 12V BY BIOS selection)
USB	USB 3.0 x 4 USB 2.0 x 2
Cash Drawer	RJ12 x 1, support 12V / 24V DC Cash Drawer
Audio	2 Watt Speaker x 1 (R channel)
Expansion Slot	M.2 2230 E-key slot x 1 (for WiFi module, included USB2.0 signal) M.2 2242 SSD Slot x 1
DC-in	19V DC Input, 2-pin jack x 1
Power Button	Power Button x 1
Giga LAN	Gigabit Ethernet by RJ-45 x 1, support Wake on LAN
Display Port	Mini DisplayPort x 1
LED	Pin Header
COM 3	RS232 pin-header x 1 (no power, optional)
COM 4	RS232 pin-header x 1 (no power, optional)
COM 6	RS232 pin-header x 1 (5V for VFD)
Power Switch	Power Switch and LED Pin Header

Power & Battery

Cash drawer

RJ12 x 1, support 12V / 4V DC Cash Drawer

Physical Dimensions

Dimension ( WxDxH )	40.2 x 18.9 x 28.8 cm
Net Weight / Gross Weight	4.3 kg.

Others

Mounting mechanism	Optional VESA-mounting bracket
Communication	Wireless LAN module, M.2 2230 E-key (optional)
Expansion Slot	M.2 2230 E-Key Slot x 1 (for WiFi module, included USB 2.0 signal) M.2 2242 SSD Slot x 1
Color	Black/White
Material	Plastic/Aluminium
Certifications	CE / FCC / VCCI / CB / WEEE / RoHS

Environmental Conditions

Storage Temperature	-20ﾟ ~ 60ﾟC
Humidity	20ﾟ ~ 85ﾟ RH (non-condensing)
Operating Temperature	0ﾟ ~ 40ﾟC
